> Triple Weber Pros..., come forward
Trekkor
post Jan 19 2005, 09:16 PM
Post #1


I do things...
*****

Group: Members
Posts: 7,809
Joined: 2-December 03
From: Napa, Ca
Member No.: 1,413
Region Association: Northern California
the motor is idling on five cylinders... (IMG:http://www.914world.com/bbs2/html/emoticons/mad.gif)

Good off idle. comes up to 7300rpms fast.

The dead hole is driver side center ( #5? )

I squirt cleaner down the barrel at idle and it picks up.
So it gets spark and will burn. Not getting any fuel at idle.

Cleaned all the idle jets.

What's next?
Help me get happier.

KT
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
2 Pages V  1 2 >
 Reply to this topicStart new topic
Replies(1 - 19)
Trekkor
post Jan 19 2005, 09:39 PM
Post #2


I do things...
*****

Group: Members
Posts: 7,809
Joined: 2-December 03
From: Napa, Ca
Member No.: 1,413
Region Association: Northern California
(IMG:http://www.914world.com/bbs2/html/emoticons/cool_shades.gif)


Attached image(s)
Attached Image
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
J P Stein
post Jan 19 2005, 09:48 PM
Post #3


Irrelevant old fart
*****

Group: Members
Posts: 8,797
Joined: 30-December 02
From: Vancouver, WA
Member No.: 45
Region Association: None
95% of the time, this is either a fouled plug or a plugged idle jet.

Did you remove the suspect jet (#5?)from the holder, hold the jet up to a light & look thru the hole....lengthwise?

Did you pull the plug, attach the plug lead, then ground the plug, and spin the motor?.....should be a nice fat spark (only do his with a cold motor & keep off the gas....ya don't even wwant it to start (IMG:http://www.914world.com/bbs2/html/emoticons/w00t.gif) )

Are you *sure* it's #5?
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
a914guy
post Jan 19 2005, 09:53 PM
Post #4


914 Master
**

Group: Members
Posts: 95
Joined: 25-December 02
From: Allen, Texas
Member No.: 11
Before you pull the carb off, disassemble it and clean it try one more attempt to clean #5s idle circuit.

The carburator (I'll assume 40IDA 3C) has a air intake on each idle circuit thats part of the top cover. Manuals reference it as as bush or air venturi.

Some carb cleaner sprayed into the idle jet hole will validate weather this is open. Don't try to clean this port with a probe as you will very likely disturb dirt and drive it into the circuit.

- Pull the air cleaner and remove the jet holder and idle jet.
- Get your favorite carb cleaner with an extension tube so you can concentrate/extend the spray easily into the idle jet hole in the carb body.
- Place a shop rag on top of each idle circuit you are cleaning, directly over this air port. Fluid will squirt out of the hole if it's clear.
- Spray carb cleaner into the hole. You might also hold a small shop rag under each circuit to catch excess spray.

If the carb is really dirty and you have an idle circuit stopped up it's probably time to clean them both.

Another indicator of contamination in the carb can be found at the bottom of the float bowls. Pull the drain pugs and carfully catch the gas. Inspect it for contamination. If you see evidence of dirt here you can be pretty sure it's trying to getting to the idle circuit as well.

Good luck!
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
Type 4
post Jan 19 2005, 09:57 PM
Post #5


Member
**

Group: Members
Posts: 412
Joined: 30-September 04
From: Costa Mesa Calif.
Member No.: 2,866
Try a $1.98 tune up.
Rev it up and hold it at 3500 rpm the take a rag and cover the intake of the dead hole .
This will creat vacuum that may clean out the crud.
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
Joe Bob
post Jan 19 2005, 10:02 PM
Post #6


Retired admin, banned a few times
***************

Group: Members
Posts: 17,427
Joined: 24-December 02
From: Boulder CO
Member No.: 5
Region Association: None
QUOTE (a914guy @ Jan 19 2005, 07:53 PM)
Before you pull the carb off, disassemble it and clean it try one more attempt to clean #5s idle circuit.

The carburator (I'll assume 40IDA 3C) has a air intake on each idle circuit thats part of the top cover. Manuals reference it as as bush or air venturi.

Some carb cleaner sprayed into the idle jet hole will validate weather this is open. Don't try to clean this port with a probe as you will very likely disturb dirt and drive it into the circuit.

- Pull the air cleaner and remove the jet holder and idle jet.
- Get your favorite carb cleaner with an extension tube so you can concentrate/extend the spray easily into the idle jet hole in the carb body.
- Place a shop rag on top of each idle circuit you are cleaning, directly over this air port. Fluid will squirt out of the hole if it's clear.
- Spray carb cleaner into the hole. You might also hold a small shop rag under each circuit to catch excess spray.

If the carb is really dirty and you have an idle circuit stopped up it's probably time to clean them both.

Another indicator of contamination in the carb can be found at the bottom of the float bowls. Pull the drain pugs and carfully catch the gas. Inspect it for contamination. If you see evidence of dirt here you can be pretty sure it's trying to getting to the idle circuit as well.

Good luck!

Well LOOK who showed up?????

Long time...... (IMG:http://www.914world.com/bbs2/html/emoticons/pray.gif)
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
McMark
post Jan 19 2005, 10:04 PM
Post #7


914 Freak!
***************

Group: Retired Admin
Posts: 20,179
Joined: 13-March 03
From: Grand Rapids, MI
Member No.: 419
Region Association: None
What about taking the idle jet out and blowing compressed air into it to dislodge clogs? (IMG:http://www.914world.com/bbs2/html/emoticons/confused24.gif) I'm talking out my ass here.
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
Sparky
post Jan 19 2005, 10:07 PM
Post #8


Mahna Mahna!
***

Group: Members
Posts: 1,134
Joined: 21-June 03
From: Spencer, MA
Member No.: 847
QUOTE (Type 4 @ Jan 19 2005, 07:57 PM)
Try a $1.98 tune up.
Rev it up and hold it at 3500 rpm the take a rag and cover the intake of the dead hole .
This will creat vacuum that may clean out the crud.

Instead of a rag try using something that wont get sucked in if you let go accidently. Don't ask......

Mike D.
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
Maltese Falcon
post Jan 19 2005, 10:17 PM
Post #9


Advanced Member
****

Group: Members
Posts: 4,894
Joined: 14-September 04
From: Mulholland SoCal
Member No.: 2,755
Region Association: None
Trekkor, we like it when you're happy...not like you just finished up a 500 SF kitchen in Brazilian Blue (IMG:http://www.914world.com/bbs2/html/emoticons/biggrin.gif)
Rich, (a914guy) good plan of attack on the carb- and thx for getting my parts out this week !
If this engine ran around in a sand buggy in its previous life, contaminination is likely.
Marty
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
Trekkor
post Jan 19 2005, 10:28 PM
Post #10


I do things...
*****

Group: Members
Posts: 7,809
Joined: 2-December 03
From: Napa, Ca
Member No.: 1,413
Region Association: Northern California
Good advice here...As always (IMG:http://www.914world.com/bbs2/html/emoticons/clap.gif)

I did rebuild and fully clean the carbs prior to installation.

However, I listened to the speed shop guy instead of checkin' in with my 914 pals. When I assembled the fuel hose barbs into the pump am regulator I used Permatex pipe compound. It may be in everything. (IMG:http://www.914world.com/bbs2/html/emoticons/unsure.gif)

Tomorrow I'll chase it again. thanks for the help, bros.

KT
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
Gint
post Jan 19 2005, 10:43 PM
Post #11


Mike Ginter
***************

Group: Admin
Posts: 16,095
Joined: 26-December 02
From: Denver CO.
Member No.: 20
Region Association: Rocky Mountains
No sealer of any kind on the carbs or fuel line.
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
Trekkor
post Jan 19 2005, 11:04 PM
Post #12


I do things...
*****

Group: Members
Posts: 7,809
Joined: 2-December 03
From: Napa, Ca
Member No.: 1,413
Region Association: Northern California
Ahhh, no way! (IMG:http://www.914world.com/bbs2/html/emoticons/headbang.gif)

I used Permatex gasket dressing on my carbs, too.

KT
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
Series9
post Jan 19 2005, 11:07 PM
Post #13


Lesbians taste like chicken.
*****

Group: Members
Posts: 5,444
Joined: 22-August 04
From: DeLand, FL
Member No.: 2,602
Region Association: South East States
I have seen this quite a bit.

In my experience, this problem is always caused by using carbs on a Porsche engine.

It's OK, though. The engine will run like new after fitting fuel injection.

(sorry, I'm really bored in my hotel room) (IMG:http://www.914world.com/bbs2/html/emoticons/cool.gif)
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
Trekkor
post Jan 19 2005, 11:14 PM
Post #14


I do things...
*****

Group: Members
Posts: 7,809
Joined: 2-December 03
From: Napa, Ca
Member No.: 1,413
Region Association: Northern California
QUOTE
(sorry, I'm really bored in my hotel room)


I will get you. (IMG:http://www.914world.com/bbs2/html/emoticons/lol2.gif)

KT
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
Root_Werks
post Jan 20 2005, 09:16 AM
Post #15


Village Idiot
*****

Group: Members
Posts: 8,507
Joined: 25-May 04
From: About 5NM from Canada
Member No.: 2,105
Region Association: Pacific Northwest
QUOTE (Gint @ Jan 19 2005, 08:43 PM)
No sealer of any kind on the carbs or fuel line.

Yep, bad, bad, bad. Carbs have too many tiny holes and galleys. A spec of dust just about clogs them up! (IMG:http://www.914world.com/bbs2/html/emoticons/ohmy.gif)
User is online!Profile CardPM
Go to the top of the page
+Quote Post
Rusty
post Jan 20 2005, 10:56 AM
Post #16


Wanted: Engine case GA003709
*****

Group: Admin
Posts: 7,952
Joined: 24-December 02
From: North Alabama
Member No.: 6
Region Association: Galt's Gulch
QUOTE (trekkor @ Jan 20 2005, 12:04 AM)
Ahhh, no way! (IMG:http://www.914world.com/bbs2/html/emoticons/headbang.gif)

I used Permatex gasket dressing on my carbs, too.

Way. (IMG:http://www.914world.com/bbs2/html/emoticons/sad.gif)

No permatex on carb gaskets, either. Sorry dood.
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
ClayPerrine
post Jan 20 2005, 11:13 AM
Post #17


Life's been good to me so far.....
***************

Group: Admin
Posts: 15,950
Joined: 11-September 03
From: Hurst, TX.
Member No.: 1,143
Region Association: NineFourteenerVille
QUOTE (trekkor @ Jan 19 2005, 11:04 PM)
Ahhh, no way! (IMG:http://www.914world.com/bbs2/html/emoticons/headbang.gif)

I used Permatex gasket dressing on my carbs, too.

KT

If you hear a very loud whirring sound coming form NorCal... its just Capt'n Crusty's head spinning......

"Use Permatex on your Carbs and YOU WILL DIE!!!!" (IMG:http://www.914world.com/bbs2/html/emoticons/chairfall.gif)


Seriously.. no sealer of any kind on the carbs, Period.
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
Root_Werks
post Jan 20 2005, 11:16 AM
Post #18


Village Idiot
*****

Group: Members
Posts: 8,507
Joined: 25-May 04
From: About 5NM from Canada
Member No.: 2,105
Region Association: Pacific Northwest
(IMG:http://www.914world.com/bbs2/html/emoticons/ohmy.gif) I think I hear trekkor beating some against something? (IMG:http://www.914world.com/bbs2/html/emoticons/headbang.gif) (IMG:http://www.914world.com/bbs2/html/emoticons/laugh.gif) Sorry Trekkor, couldn't resist. No worries man, you will get it. (IMG:http://www.914world.com/bbs2/html/emoticons/smile.gif)
User is online!Profile CardPM
Go to the top of the page
+Quote Post
Rusty
post Jan 20 2005, 12:50 PM
Post #19


Wanted: Engine case GA003709
*****

Group: Admin
Posts: 7,952
Joined: 24-December 02
From: North Alabama
Member No.: 6
Region Association: Galt's Gulch
On the other hand... check the resistance of your plug wires. If you get something like 3000 ohms, you'll know that you need to run out to your FLAPS, find some old chebby wires, cut the ends off of them, and install your 914 ends.

Voila... el cheapo plug wires! Warrantied for the first 5 miles you drive the car! (IMG:http://www.914world.com/bbs2/html/emoticons/smile.gif)
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
Trekkor
post Jan 20 2005, 12:55 PM
Post #20


I do things...
*****

Group: Members
Posts: 7,809
Joined: 2-December 03
From: Napa, Ca
Member No.: 1,413
Region Association: Northern California
(IMG:http://www.914world.com/bbs2/html/emoticons/dry.gif)

Soooo, the expanding foam would be bad as a sealant for the air filters, too. (IMG:http://www.914world.com/bbs2/html/emoticons/cool_shades.gif)

(IMG:http://www.914world.com/bbs2/html/emoticons/lol2.gif)

No one's that dingy...

KT


( new plugs and wires OEM $$$ )
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
« Next Oldest · 914World Garage · Next Newest »


2 Pages V  1 2 >
Reply to this topicStart new topic
2 User(s) are reading this topic (2 Guests and 0 Anonymous Users)
0 Members:



Display Mode: Switch to: Standard · Linear+ · Switch to: Outline

Track this topic · Email this topic · Print this topic · Subscribe to this forum

- Lo-Fi Version Time is now: 26th December 2024 - 10:42 AM
Invision Power Board v9.1.4 © 2024  IPS, Inc.
All rights reserved 914World.com © since 2002
914World.com is the fastest growing online 914 community!
We have it all, classifieds, events, forums, vendors, parts, autocross, racing, technical articles, events calendar, newsletter, restoration, gallery, archives, history and more for your Porsche 914 ...
