> smog pump
yellow1
post Apr 22 2008, 11:54 PM
Post #1


Newbie
*

Group: Members
Posts: 48
Joined: 7-September 07
From: NY
Member No.: 8,090
The pump was removed from my car and pluged as u see in the pic,is this okay or should all of the egr system be removed. Attached Image
User is offlineProfile CardPM
Go to the top of the page
+Quote Post

 Reply to this topicStart new topic
Replies(1 - 15)
jcd914
post Apr 23 2008, 12:06 AM
Post #2


Advanced Member
****

Group: Members
Posts: 2,081
Joined: 7-February 08
From: Sacramento, CA
Member No.: 8,684
Region Association: Northern California

If you don't have to worry about smog equipment then you can remove the rest of the injection tubing but it is not necessary. It is easiest to take the injection manifold (no 19 in your pic) off and put caps on the injectors (no 20 in your pic). You won't gain any performance but it gets some of the clutter out of the engine compartment. EGR is a separate system.

Jim
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
Loser_Cruiser
post Apr 23 2008, 12:11 AM
Post #3


Member
**

Group: Members
Posts: 407
Joined: 4-April 05
From: Bellingham, WA
Member No.: 3,873
Region Association: Pacific Northwest
anyone know what these things are selling for in good condition?
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
JeffBowlsby
post Apr 23 2008, 08:35 AM
Post #4


914 Wiring Harnesses
*****

Group: Members
Posts: 8,781
Joined: 7-January 03
From: San Ramon CA
Member No.: 104
Region Association: None
I know this is not popular thinking, but why not locate another smog pump and hook it back up again? It is the way your 914 was meant to be. (IMG:style_emoticons/default/biggrin.gif)
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
VaccaRabite
post Apr 23 2008, 09:32 AM
Post #5


En Garde!
**********

Group: Admin
Posts: 13,616
Joined: 15-December 03
From: Dallastown, PA
Member No.: 1,435
Region Association: MidAtlantic Region
If you delete the smog equipment and backdate to a 74 exhaust, you will pick up HP. You will also drop about 20 pounds.

If NY does not check for emissions equipment, then I would do it.

Zach
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
yellow1
post Apr 23 2008, 11:52 PM
Post #6


Newbie
*

Group: Members
Posts: 48
Joined: 7-September 07
From: NY
Member No.: 8,090
QUOTE(jcd914 @ Apr 22 2008, 10:06 PM) *

If you don't have to worry about smog equipment then you can remove the rest of the injection tubing but it is not necessary. It is easiest to take the injection manifold (no 19 in your pic) off and put caps on the injectors (no 20 in your pic). You won't gain any performance but it gets some of the clutter out of the engine compartment. EGR is a separate system.

Jim

Thx jcd914 for the quick reply and your help greatly appreciated.
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
yellow1
post Apr 24 2008, 12:00 AM
Post #7


Newbie
*

Group: Members
Posts: 48
Joined: 7-September 07
From: NY
Member No.: 8,090
QUOTE(Vacca Rabite @ Apr 23 2008, 07:32 AM) *

If you delete the smog equipment and backdate to a 74 exhaust, you will pick up HP. You will also drop about 20 pounds.

If NY does not check for emissions equipment, then I would do it.

Zach

Thx Vacca Rabite for the info,mabey in the future i will replace the exahaust,for now i have it pluged it where the arrow is pointed ,just wanted to make sure the car would run okay like this.I did remove the pump but left all of the plumbing.
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
ericread
post Apr 24 2008, 12:06 AM
Post #8


The Viper Blue 914
****

Group: Members
Posts: 2,177
Joined: 7-December 07
From: Irvine, CA (The OC)
Member No.: 8,432
Region Association: Southern California
(IMG:style_emoticons/default/agree.gif)

The SMOG pump was a bad idea when it was initially used as a "Rube Goldberg" device to bring emissions down a bit. It didn't really lower emissions, it just diluted the exhaust so that the emissions would seem cleaner. (IMG:style_emoticons/default/headbang.gif)

Glad to hear you're able to get rid of it. HOWEVER, save all of the plumbing. Should your State decide in the future that original SMOG equipment is required, having the plumbing will allow you to mock up the unit for licensing purposes. From what I have seen, the SMOG pump plumbing is getting less available all the time.

Good luck and please keep posting your progress!!! (IMG:style_emoticons/default/aktion035.gif)
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
yellow1
post Apr 24 2008, 12:13 AM
Post #9


Newbie
*

Group: Members
Posts: 48
Joined: 7-September 07
From: NY
Member No.: 8,090
QUOTE(Jeff Bowlsby @ Apr 23 2008, 06:35 AM) *

I know this is not popular thinking, but why not locate another smog pump and hook it back up again? It is the way your 914 was meant to be. (IMG:style_emoticons/default/biggrin.gif)

I dont have a problem with pump,my alternater belt flew off and to get a new 1 in was very difficult for me because the smog pump bracket is in the way.why dont i just put the pump back on ,because if the belt comes off or breaks in the future, replacing it is very easy without it in the way u can even do it with out tools if u have to.with the pump on u need tools jacks or ramps and a lot patience.
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
yellow1
post Apr 24 2008, 12:32 AM
Post #10


Newbie
*

Group: Members
Posts: 48
Joined: 7-September 07
From: NY
Member No.: 8,090
QUOTE(Loser_Cruiser @ Apr 22 2008, 10:11 PM) *

anyone know what these things are selling for in good condition?

auto atlanta sells the pump used for $250.00 new $493.42 that does not include the air cleaner part if u need that add $45.00 used or $154.63 new ,if u need the bracket a used 1 is $450.00 new 657.90
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
stateofidleness
post Apr 24 2008, 01:00 AM
Post #11


Senior Member
***

Group: Members
Posts: 810
Joined: 1-September 07
From: Canyon Lake, Texas!
Member No.: 8,065
Region Association: None
well if anyone needs one i have one for sale

instead of leaving those injectors (#20) installed, can you unscrew them and plug it at the head? how would you do this?
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
drive-ability
post Apr 24 2008, 01:16 AM
Post #12


Senior Member
***

Group: Members
Posts: 1,169
Joined: 18-March 05
From: Orange County, California
Member No.: 3,782
QUOTE(ericread @ Apr 23 2008, 11:06 PM) *

(IMG:style_emoticons/default/agree.gif)

The SMOG pump was a bad idea when it was initially used as a "Rube Goldberg" device to bring emissions down a bit. It didn't really lower emissions, it just diluted the exhaust so that the emissions would seem cleaner. (IMG:style_emoticons/default/headbang.gif)

Glad to hear you're able to get rid of it. HOWEVER, save all of the plumbing. Should your State decide in the future that original SMOG equipment is required, having the plumbing will allow you to mock up the unit for licensing purposes. From what I have seen, the SMOG pump plumbing is getting less available all the time.

Good luck and please keep posting your progress!!! (IMG:style_emoticons/default/aktion035.gif)



The reality was back then the pump didn't dilute the system it was designed to introduce O2 in the exhaust as close to the exhaust valves as they could get it, there it would add more 02 the keep the fuel burning or ignite it.. You see rich mixtures burn off all the 02 and leave extra gas left this system would help burn off the excess.
I agree it was a patch, but before modern computers it was as good as it gets. The same is true with the Cat Converter because even with modern EFI systems when you nail the throttle theres extra fuel left over, the cat does a good job handling it ...
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
ericread
post Apr 24 2008, 01:24 AM
Post #13


The Viper Blue 914
****

Group: Members
Posts: 2,177
Joined: 7-December 07
From: Irvine, CA (The OC)
Member No.: 8,432
Region Association: Southern California
The reality was back then the pump didn't dilute the system it was designed to introduce O2 in the exhaust as close to the exhaust valves as they could get it, there it would add more 02 the keep the fuel burning or ignite it.. You see rich mixtures burn off all the 02 and leave extra gas left this system would help burn off the excess.
I agree it was a patch, but before modern computers it was as good as it gets. The same is true with the Cat Converter because even with modern EFI systems when you nail the throttle theres extra fuel left over, the cat does a good job handling it ...
[/quote]

Nice job in providing better accuracy! (IMG:style_emoticons/default/pray.gif) I still believe it was an ugly patch! (IMG:style_emoticons/default/wacko.gif)
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
Solocholo
post Jul 20 2021, 04:20 PM
Post #14


Newbie
*

Group: Members
Posts: 7
Joined: 20-July 21
From: California
Member No.: 25,739
Region Association: Southern California
Nice thanks for the info, I’m going to cap mine off too (IMG:style_emoticons/default/piratenanner.gif) (IMG:style_emoticons/default/piratenanner.gif) (IMG:style_emoticons/default/sawzall-smiley.gif)
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
Rand
post Jul 20 2021, 05:19 PM
Post #15


Cross Member
*****

Group: Members
Posts: 7,409
Joined: 8-February 05
From: OR
Member No.: 3,573
Region Association: None
There is nothing good about the smog pump. Just be sure you seal the head well. A common trick is a ball bearing in the cap of a fitting that screws into the the air-injection port.
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
Rand
post Jul 20 2021, 05:21 PM
Post #16


Cross Member
*****

Group: Members
Posts: 7,409
Joined: 8-February 05
From: OR
Member No.: 3,573
Region Association: None
QUOTE(Jeff Bowlsby @ Apr 23 2008, 07:35 AM) *

I know this is not popular thinking, but why not locate another smog pump and hook it back up again? It is the way your 914 was meant to be. (IMG:style_emoticons/default/biggrin.gif)

It is DEFINITLY NOT the way the 914 was meant to be. 914s never came with them until some stupid regulations forced it later against their will/design. It's bullshit that was forced in the late 70s when they were overbearingly trying to figure out smog and it sucks in every way. It is extra junk that only hurts performance. It is a leech. If you don't HAVE to have it for registration, get rid of it stat! Just block off the head port securely (get this right), remove the garbage, and enjoy a simpler system with better efficiency and more power.


PS: I have had 110% respect for Jeff for decades, an icon among us. Do not take this as me debating him. Just had to push back a little. (IMG:style_emoticons/default/smile.gif)


Attached image(s)
Attached Image Attached Image
User is offlineProfile CardPM
Go to the top of the page
+Quote Post
