My new 2.0 won't start, Need help!! Options

[kkid]

Hi guys,

I spent last few weeks to prep on my newly acquired 2.0 and it's finally in the car! But she doesn't wanna wake up.... (IMG:style_emoticons/default/sad.gif) I know our Bay has been cold lately...but today is beautiful!!!

It turns over, has fuel pressure around 30psi when cranking(20psi soon after when the key turned off), static timing done after points gap adjusted, all the electrical connections checked I think, and what else???

Actually there're at least 2 concerns I can think of. When I got the motor, the dizzy rotor was pointing somewhere around#4 position when the TDC mark was showing in the round window. So I moved the gear in order for rotor to point #1 as I confirmed the valves were loose. But wondering if I did it correctly. I took the gas tank out as I installed stainless fuel lines. The tank was sitting in my garage for about a week or so then it developed some rust. So I cleaned inside with rust remover. But I might not have rinsed it well enough. New fuel filter still looks clean after uncountable numbers of attempt of starting the motor. New fuel sock is in the tank.




So I am stuck now (IMG:style_emoticons/default/sad.gif) (IMG:style_emoticons/default/sad.gif) (IMG:style_emoticons/default/sad.gif) (IMG:style_emoticons/default/sad.gif) (IMG:style_emoticons/default/sad.gif) (IMG:style_emoticons/default/sad.gif)

What do you all think I screwed?

Thanks in advance,

kkid (IMG:style_emoticons/default/smile.gif)

[kkid]

Update with news

Good: I am on the road again! (IMG:style_emoticons/default/smile.gif) Damn it! How fun the car is!! (IMG:style_emoticons/default/driving-girl.gif)

Bad: Still running with the old motor! Damn it!! (IMG:style_emoticons/default/smash.gif) Don't tell my wife about it. (IMG:style_emoticons/default/sad.gif)



Yes, I pulled the new motor out and put the old one back in there. That's the only way to get the car running at this point and started right up as usual.

The new motor still squeals (by hand rotations) even if it's out of the car, even with/without the fan. The internal noise seems to come out from of the case or between the case and head area. I now realized it cranked with the starter slower than normal. Will post the piggy squeal on youtube later.

This is what I did or changed/installed on the new motor(maybe more but as far as I remember).

1. New crankshaft seals f/r
2. New injector seals
3. Valve adjustment
4. Adjusted the end play and shimmed to the spec
5. New plugs
6. New ignition wires
7. New ignition points
8. New ignition condenser
9. Changed passenger side and corner engine sheet metals(motor came with sheet metal with holes for a/c compressor)
10. Changed hardware for alternator bracket
11. New fuel filter
12. Stainless fuel lines from Tangerine Racing
13. New fuel hoses
14. Rotated the dizzy drive gear to get a correct alignment
15. Static timing
16. New oil and filter
17. Primed the oil system prior to the starting
18. Recharged battery
19. New dizzy cap
20. New exhaust studs(6 out of 8) on the heads - the motor came with heat exchangers installed but 5 nuts were rusted and unable to loosen so had to take the nuts and studs all together then installed new ones. 1 stud was loose and looked to be glued with an epoxy like a JB weld!
21. Cleaned gas tank then installed a new sock and hoses underneath
22. Newer clutch assembly from other motor(less than 10k miles)
23. Alternator seal(rubber spacer)
24. Stainless engine sheet metal screws from 914rubber.com
25. Terry's accelerator cable
26. added TDC(white) and timing(red) marks on the other edge of the cooling fan
27. New seal and washers on taco plate
28. Readjusted fuel pressure @ 29PSI+ with a gauge
29. New intake runner hoses
30. Disconnected cold start valve fuel hose for fuel pressure gauge
31. don't remember...

My advice --- Don't buy a motor that has never been fired up or tested. It may not run like mine. Even if it's rebuilt it may not run specially if it's a resale item that a seller has no idea how it's built. Buy an engine that is still on a car or with a recent bench test result.

Now what should I do with the motor? Should I take it to Mark to examine? Well, my time and money were well spent for this phase.

I believe the seller won't take it back after we found out it has a failure. So I will tear it down to find out the problem and rebuild myself.
My journey will begin.

Thanks for reading.

Have a great day!

kkid (IMG:style_emoticons/default/smile.gif)
